DH-HAC-HDW1200TLM-IL-A – 2MP Smart Dual Light HDCVI Eyeball Camera
The DH-HAC-HDW1200TLM-IL-A is a high-performance 2MP HDCVI eyeball camera designed for reliable day and night surveillance. Equipped with Smart Dual Light technology, it intelligently switches between infrared and warm light to deliver clear, full-color images when activity is detected while maintaining energy efficiency. Its metal housing and IP67 rating ensure stable operation in demanding indoor and outdoor environments.
Key Features
- 2MP CMOS sensor with Full HD 1080p resolution
- Smart Dual Light technology (IR + warm light)
- Clear color images with extremely low illumination
- Up to 20 m IR and warm light illumination distance
- Wide-angle viewing with 2.8 mm or 3.6 mm fixed lens
- DWDR, BLC, and HLC for balanced exposure
- 3D Noise Reduction for cleaner video output
- Built-in microphone for real-time audio recording
- IP67 weatherproof metal housing
Technical Specifications
- Image Sensor: 2 MP CMOS
- Maximum Resolution: 1920 × 1080 (1080p)
- Minimum Illumination: 0.01 lux (Color), 0 lux (Illuminator on)
- Lens Options: 2.8 mm / 3.6 mm, F2.0
- Viewing Angle: Up to 102° horizontal
- DORI Distance: Detect up to 50.9 m (3.6 mm)
- Video Output: CVI / TVI / AHD / CVBS via BNC
- Audio Input: 1 channel
- Power Supply: 12V DC ±30%
- Power Consumption: Max 2.6W
- Operating Temperature: –40°C to +60°C
- Protection Level: IP67
Ideal Applications
- Residential and apartment security
- Retail shops and shopping areas
- Office buildings and corridors
- Warehouses and parking areas
- Outdoor perimeter monitoring
